StarTech Com 7m LC TO SC OS2 Fiber, 7m Cable, Ceramic Construction, Compatible With OS1 Networks, Ensuring A Reliable Connection IN Legacy Fiber Environments

22.7ft LC/SC-UPC OS2 Single Mode fiber cable is optimized for 10G networks; Coarse Wavelength Division Multiplexing (CWDM) enables extended 1260-1625nm wavelength support for long distance channel isolationUPC-polished ends for minimal return loss; Molded strain reliefs; Bend Insensitive Fiber Core in Aramid-reinforced LSZH Jacket for a loaded bend radius of 10mmConnect between servers/switches and data center equipment9/125 m; OD: 2mm; Temp Range: -20 to 60C (-4 to 140F)

OS2 LC to SC Single Mode Duplex Fiber Optic Patch cable facilitates connectivity across 100G networks. It supports Coarse Wavelength Division Multiplexing (CWDM) across an extended wavelength range of 1260-1625nm, improving channel isolation for optimal signal strength over long distances.

Compatibility

This 9/125µm Single Mode fiber cable supports 1260-1625nm laser-optimized sources and is ideal for critical connections between servers, switches, and data center equipment. It is backward compatible with OS1 networks, ensuring a reliable connection in legacy fiber environments.

Engineered for Optimal Performance

Precision-manufactured ceramic ferrules ensure accurate fiber alignment for an insertion loss below 0.3dB. Ultra Physical Contact (UPC)-polished LC to SC fiber ends greatly improve return loss characteristics over older PC polishing techniques. The Bend Insensitive fiber core is surrounded by a layer of low refractive index material. This material reduces the amount of light that can escape the fiber cable by reflecting the light back into the fiber. The OS2 fiber patch cord is engineered for low attenuation and performance that exceeds ITU-T G652.D/G657.A1 and IEC60703-2-50 type B1.3/B6.a1 industry standards.

LSZH Cable Jacket

Housed in a Low-Smoke Zero-Halogen (LSZH) flame-retardant jacket, the OS2 fiber cable emits low smoke and toxic fumes when exposed to extreme heat or in the event of a fire. This enables safer cable installations in areas with poor ventilation including some industrial settings, self-contained environments such as trains and aircraft, as well as residential settings where compliance with building codes must be considered.

Each OS2 fiber cable is individually tested for insertion loss performance and includes a test report, for guaranteed compatibility and 100% reliability.

• Experience a simpler way to connect devices with the entire business network


• Features Fiber Optic cable type for your convenience and desired usability


• Laser-optimized feature for better usability and increased efficiency


• Network Device device supported according to your requirements with maximum productivity
