Eaton Environmental Monitoring Probe ePDU Connectivity Device, 65.6 FT Cable, The EMP Measures Temperatures From 32°F TO 158°F 0°C TO 70

Eaton Environmental Monitoring Probe ePDU Connectivity Device
The optional environmental monitoring probe (EMP) is a connectivity device that enables you to collect temperature and humidity readings in the rack environment and monitor the environmental data remotely via the onboard LCD screen or remotely using a Telnet connection or a standard web browser. You can also collect and retrieve the status of two contact devices.

• When temperature and humidity values exceed user-selectable limits, the event is logged in the ePDU event history log.


• The EMP monitors temperature and humidity information of any environment that you want to protect your critical equipment. The EMP measures temperatures from 32°F to 158°F (0°C to 70°C) with an accuracy of ±3.6°F (±2°C).


• The EMP measures relative humidity from 10% to 90% with an accuracy of ±5%.


• It can be located away from the ePDU with a CAT5 network cable up to 65.6 ft (20 m) long.


• The hot-swap feature simplifies installation by enabling you to install the probe safely without turning off power to the ePDU or to the loads that are connected to it.


• The EMP monitors the status of the two user-provided contact devices.


• Temperature, humidity, and contact closure status can be displayed through a web browser, a serial interface, or an onboard LCD interface.


• User-selectable alarm thresholds enable you to define acceptable temperature or humidity limits.


• Email notification through Simple Mail Transfer Protocol (SMTP), using email client software when acceptable alarm limits are exceeded or contact status changes.


• Changes in external contact status are logged in the ePDU event history log.
