ComNet 4 Channel Video/Audio Transmitter

The ComNet™ FVT/FVR40A4 series video/audio multiplexer utilizes 10-bit video encoding for true EIA/TIA RS-250C Short-Haul broadcast quality transmission, and 24-bit encoding at a 96 Khz sampling rate for the highest possible audio fidelity. Digitally encoded transmission ensures that the video and audio performance remain completely unaffected up to the maximum usable optical transmission distance or optical path loss. These environmentally hardened units provide the transmission of four independent simplex video and four independent simplex line-level audio channels over one multimode or single mode optical fiber. The FVT/FVR40A4 series is completely transparent to and universally compatible with any NTSC, PAL, or SECAM camera system. Plug-and-play design ensures ease of installation, and no electrical or optical adjustments are ever required.

• Voltage transient protection on all power and signal input/ output line provide protection from voltage surges and other transient events


• Designed for installation in harsh out-of-plant/unconditioned industrial or roadside operating environments (-40 to +75C ambient). Fully compliant with the environmental requirements of NEMA TS-2 for Traffic Signal Control Equipment


• Optical transmission distances of up to 48 km (30 miles)


• Wide optical dynamic range: optical attenuators are never required


• Line-Level 600 ohm balanced audio input and audio output at a maximum level of +6dBm


• Directly compatible with all NTSC, PAL, and SECAM CCTV camera systems


• 20Hz to 18Khz audio frequency response


• Digitally Encoded Transmission: No video or audio performance degradation up to the maximum usable optical transmission distance or optical path loss


• 4 channels of 24-bit/96 Khz sampling rate digitally encoded audio for the highest possible audio quality


• 4 channels of real-time 10-bit digitally encoded EIA/TIA RS-250C Short-Haul quality video on one optical fiber
