ACRE ComNet 2-Channel Audio Transceiver "B" End, 157480.31 ft, FXA2C1S1B, Wired

ComNet 2-Channel Audio Transceiver "B" End

The ComNet™ FTA/FRA2C1 Series audio multiplexer provides the transmission of two audio signals and one contact closure over one multimode or single mode optical fiber. A bidirectional model, FXA2C1(M,S)1, is also available. The modules use 24-bit 96kHz sample rate digital encoding for superior transmission of balanced line-level audio. Plug- and-play design ensures ease of installation and no electrical or optical adjustments are required. Bi-color LED indicators confirm operational status. Packaged in the exclusive ComNet ComFit housing, these units may be either wall or rack mounted.

• Automatic resettable fuses on all power lines


• Bi-color LED status indicators confirm operating status


• Transmits balanced line-level audio up to +8.5dBm


• Distances up to 48km (30mi) without repeaters


• No in-field electrical or optical adjustments required


• 20Hz - 20kHz audio bandwidth


• 600Ω audio input impedance


• One simplex or duplex contact closure


• 24-bit 96kHz digitally encoded transmission


• Two simplex or duplex audio channels
