Gefen 4K Ultra HD HDBaseT Extender, 130ft/40m HDMI & Bi-Directional IR, 12-bit Deep Color, HDR, Dolby Atmos, HDCP 2.2, 7.1 LPCM

Gefen 4K Ultra HD HDBaseT Extender, 130ft/40m HDMI & Bi-Directional IR, 12-bit Deep Color, HDR, Dolby Atmos, HDCP 2.2, 7.1 LPCM

With 2-way IR, and POL

The GTB-UHD-HBTL 4K Ultra HD Extender uses Gefen's implementation of the HDBaseT™ technology to extend HDMI up to 230 feet/70 meters at 1080p and up to 130 feet/40 meters at 4K, using one CAT-5e or better cable. Resolutions up to 4K Ultra HD (3840 x 2160 @ 60 Hz 4:2:0) with 7.1 channels of HBR (High Bit Rate) lossless digital audio are supported. This product provides 2-way IR extension between the Sender and the Receiver units, facilitating the control of A/V sources placed near the Sender unit and sending automation commands to the display or another device placed near the Receiver unit. Gefen's Bi-Directional POL (Power Over Line) technology powers the Sender or the Receiver unit using the same cable that extends the HDMI signal. Only one of the two units will need a power supply. This feature simplifies installation in cases when an electrical outlet may not be available near the source or the display. Small, low profile enclosures can be securely surface-mounted and conveniently hidden away from sight.

• CEC pass-through


• 3DTV pass-through


• 12-bit Deep Color


• LPCM 7.1, Dolby Atmos®, Dolby® TrueHD, DTS:X™, and DTS-HD Master Audio™ pass-through


• HDMI 2.0


• HDCP 2.2 and 1.4


• 1080p Full HD (60 Hz), up to 230 feet/70 meters (up to 12-bit Deep Color)


• 4K Cinema (DCI) (4096 x 2160 @ 24 or 30 Hz 4:4:4), up to 130 feet/40 meters (8-bit color)


• 4K Ultra HD (3840 x 2160 @ 30 Hz, 4:4:4), up to 130 feet/40 meters (8-bit color)


• 4K Ultra HD (3840 x 2160 @ 60 Hz, 4:2:0), up to 130 feet/40 meters (8-bit color)
