Tycon Power TP-POE-24IR-CI Poewr over Ethernet Injector

Tycon Power TP-POE-24IR-CI Poewr over Ethernet Injector

The TP-POE Power Over Ethernet Power Sources offered by Tycon Power Systems are quality power sources for years of reliable operation even in the toughest conditions. They accept data-in to a shielded RJ45 Jack and provide data-out and power on the shielded RJ45 output jack. They work by supplying power to the remote device on the unused Ethernet pins 4,5(V+) and 7,8(V-). The Ethernet spec supports distances up to 100m (328 feet).

The TP-POE are autoranging so that they accept AC inputs from 90VAC to 264VAC (50/60 Hz) and they supply regulated DC Voltage at the output. They have various protections for surge, short circuit and overload. The medium power models (TP-POE) have power output up to 24W and the high power models (TP-POE-HP) up to 50W. They are available in 18V, 24V and 48V DC Output with load regulation within 5%.

The TP-POE-24IR-CI is a special 24V output POE Inserter with current indicator LED and a reverse voltage pinout. Power is supplied on pins 4,5(V-) and 7,8(V+).

If the remote device does not support power over Ethernet, splitters (TP-POE-SPLT) are available to split the data and DC voltage at the remote device.
