KanexPro NetworkAV H.264 HDMI Transmitter over IP w/ POE & RS-232

KanexPro NetworkAV H.264 HDMI Transmitter over IP w/ POE & RS-232

The KanexPro EXT-AVIPH264TX is an AV over IP transmitter with an HDMI input and Ethernet out which uses advanced H.264 compression algorithm to transmit full HD 1080p from HDMI based sources with less bandwidth over LAN network. It supports PoE (power over Ethernet) with distances over a single CATx up to 394 ft. (120m) delivering one to one, one to many and many to many over the Ethernet switch.

Applications:

Ideal for digital signage and networked AV applications where full HD 1080p can be passed over IP network delivering full audio, video, power, data and control using a single Ethernet cable.

• Support LPCM audio format


• Smart IP Address Setting: Dynamic Host Configuration Protocol (DHCP)


• Can be cascaded to multiple AV over IP Extenders


• Dual power input: 802.3af compliant w/ POE & DC 5V


• (No need power supply when connecting with POE Switch)


• Supports one to many, many to many and point to point broadcasting


• H.264 Compression technology


• Can be used with DVI connection


• Features real-time AV coding and decoding to broadcast 1080p


• Encode and extend pure 1080p resolutions up to 394' / 120 meters
