KanexPro NetworkAV H.264 HDMI Receiver over IP w/ POE & RS-232

KanexPro NetworkAV H.264 HDMI Receiver over IP w/ POE & RS-232

The KanexPro EXT-AVIPH264RX is a DHCP enabled AV over IP receiver with HDMI output to display and Ethernet. This receiver over IP uses advanced H.264 compression algorithm to transmit full HD 1080p from HDMI based displays with less bandwidth over LAN network. It supports PoE (power over Ethernet) with distances over a single CATx up to 394 ft. (120m) delivering one to one, one to many and many to many over the Ethernet switch.

Applications:

Ideal for digital signage and networked AV applications where full HD 1080p can be passed over IP network delivering full audio, video, power, data and control using a single Ethernet cable.

Please note: Power over Ethernet will be supported only with a PoE enabled network switch.

• Supports LPCM audio format


• Smart IP Address Setting: Dynamic Host Configuration Protocol (DHCP)


• Can be cascaded to multiple extenders


• No power needed when connecting through a POE network switch


• Dual power input: 802.3af compliant w/ POE & DC 5V


• Supports one to many, many to many and point to point broadcasting


• Can be used with DVI connection


• H.264 Compression technology


• Features real-time AV coding and decoding to broadcast 1080p


• Decode & extend pure 1080p resolutions up to 394' / 120 meters
