The ComNet FVT/FVR10D1E series video transmitter/receiver and data transceiver supports the simultaneous transmission of short haul quality 10-bit EIA RS-250C digital video with one bi-directional data channel plus one 10/100 Mbps fast Ethernet port. The modules are universally compatible with major CCTV camera manufacturers and supports RS232, RS422 and 2 or 4-wire RS485 data interfaces and most data protocols. It also supports "up-the-coax" data transmission from most major manufacturers. Packaged in the exclusive ComNet ComFit housing, the FVT/ FVR10D1E units may be either wall or rack-mounted, or may be DIN-rail mounted by the addition of ComNet model DINBKT1 adaptor plate.

• 10-bit digital video transmission


• One bi-directional data channel


• One 10/100 BASE-T/TX fast Ethernet port


• IEEE 802.3 compliant Automatic MDI/MDI-X crossover


• Exceeds all requirements for RS-250C short-haul transmission: True broadcast video performance


• Compatible with all NTSC, PAL, or SECAM CCTV camera systems


• Certified to the requirements of NEMA TS-1/TS-2 and the Caltrans Specification for Traffic Signal Control Equipment.


• Voltage transient protection on all power and signal input/ output lines provides unconditional protection from power surges and other voltage transient events.


• Automatic resettable fuses on all power lines


• Distances up to 30 miles (48 km)
