ComNet 2 Channel Analog and IP Video over COAX Receiver
The ComNet™ CL(T,R)VE(1,2)COAX[POE][/M] is a communications link that combines composite analog baseband video and 10/100T(X) Ethernet on a single RG59 coaxial cable and transmits it up to 500 meters. The device is particularly suited to applications where the addition of IP Video to an existing analog video system is required. The CLTVE1COAXPOE/M model can provide power to the IP device via PoE.

• Single or Dual Channel Receiver


• Single-Channel Transmitter with optional IEEE 802.3at PoE power capability from 24VAC


• Continuous Receiver to Transmitter Ethernet throughput up to 4Mbps


• Continuous Transmitter to Receiver Ethernet throughput up to 36Mbps


• Full-duplex digital communications


• Proprietary adaptive analog equalizer for extending the reach of composite analog video


• Simultaneous transmission of IP video, and composite analog video up to 500m over RG59 coaxial cable
